The Tangent Theta TT525P 5-25x56 with the Horus Tremor3 reticle is a first-focal-plane precision scope for long-range competitors and marksmen who would rather hold on a grid than dial every shot. It is hand-built in Halifax, Nova Scotia, around a 34 mm one-piece tube, with 0.1 mrad turrets, 30 mrad of internal elevation and a side parallax dial that focuses from 50 m to infinity. Because the reticle sits in the first focal plane, every Tremor3 hold reads the same at 5x as it does at 25x.
This is the black, standard-turret Tremor3 model (800100-0008). The other TT525P models share this body and differ in reticle and finish. Where the Gen 3 XR models use an open tree, the Tremor3 fills the lower field with a Horus grid at 0.2 mrad spacing. It adds time-of-flight wind dots, moving-target leads for targets up to 10 mph and rapid range bars. Horus licensing limits illumination to the center dot and the 2, 4, 6 and 8 mrad dots below the horizontal line. Tangent Theta sets that illumination for low light and clip-on night vision, so it may be hard to see in full daylight.
Key features
- Horus Tremor3 grid reticle - 0.2 mrad grid, wind dots and lead marks let you hold for wind and movers without touching the turrets.
- TOOL-LESS RE-ZERO turrets - reset either dial to zero by hand, with no tools and no loose screws (US Patent 10,591,253).
- Double-turn elevation - 28 mrad on the dial, with a pop-up pin that tells you you're on the second revolution and a zero stop for a quick return.
- Non-translating dials - elevation and windage stay at the same height as they turn, in 0.1 mrad clicks.
- Night-vision-friendly illumination - 11 red LED settings with an off position between each and a 6-hour auto shut-off.
- Built for field abuse - waterproof for 4 hours at 10 m, shock-rated to 1,000 g for 10,000 cycles, and usable from -45 to +65 C.
Specifications
| Manufacturer part # | 800100-0008 |
|---|---|
| UPC | 666595531246 |
| Model | TT525P Professional, 5-25x56mm |
| Magnification | 5x-25x |
| Objective lens | 56 mm |
| Main tube diameter | 34 mm |
| Focal plane | First focal plane (FFP) |
| Reticle | Horus Tremor3 (mrad grid), illuminated center dot and 2/4/6/8 mrad dots |
| Adjustment units / click value | 0.1 mrad per click |
| Total internal adjustment | Elevation 30 mrad (103 MOA); windage +/- 10 mrad (+/- 34 MOA) |
| Working adjustment range | Elevation 28 mrad (96 MOA); windage +/- 6 mrad (+/- 20 MOA) |
| Elevation dial | Double turn, 28 mrad, with revolution indicator pin and zero stop |
| Windage dial | Single turn |
| Turrets | Non-translating, TOOL-LESS RE-ZERO (US Patent 10,591,253); standard turrets, AIF option not fitted |
| Adjustment direction | Counter-clockwise up, counter-clockwise right |
| Parallax adjustment | Side dial, 50 m to infinity |
| Field of view @ 5x | 4.3 degrees (7.6 m @ 100 m) |
| Field of view @ 25x | 0.9 degrees (1.6 m @ 100 m) |
| Eye relief | 90 mm (3.54 in) |
| Exit pupil | 11 mm @ 5x; 2.3 mm @ 25x |
| Diopter range | -3 to +2.5, lockable |
| Reticle illumination | Red LED, 11 settings with off detent between each, 6-hour auto shut-off |
| Battery | CR2032 or DL2032 3 V lithium |
| Length | 425 mm (16.7 in) |
| Width / height | 103 mm / 86 mm |
| Weight | 1,150 g (40.6 oz) |
| Objective bell / eyepiece diameter | 65 mm / 45 mm |
| Exterior finish | Type II anodized, matte black |
| Waterproof | 4 hours @ 10 m |
| Shockproof | 1,000 g @ 10,000 cycles |
| Operating temperature | -45 C to +65 C (-49 F to +149 F) |
| Storage temperature | -51 C to +85 C |
| Recommended ring torque | Up to 25 in-lb |
| Country of manufacture | Canada (Halifax, Nova Scotia) |
In the box
- Riflescope with CR2032/DL2032 battery installed
- Tenebraex KillFlash anti-reflection device (ARD)
- Tenebraex Tactical Tough objective and ocular lens covers
- Lens pen
Warranty
Tangent Theta riflescopes carry a lifetime warranty against manufacturer defects. Warranty and non-warranty repairs are handled at the Armament Technology facility in Halifax, Nova Scotia, and a return authorization (RMA) is required before shipping a scope in for service.
