The Trijicon Credo 1-8x28 (CR828-C-2900056) is a Coyote Brown, first focal plane low-power variable riflescope with a red/green illuminated MRAD Segmented Circle reticle, made for carbine, competition and duty shooters who need speed up close and holds at distance. At 1x the segmented circle works like a red dot sight for both-eyes-open shooting, and at 8x the mil-hashed stadia let you hold for drop and wind. The 34 mm tube and 28 mm objective give a larger exit pupil than a 24 mm design, which helps in dim light.
This is the Coyote Brown anodized MRAD model, a finish Trijicon added for 2025. It shares its glass and adjusters with the matte black MRAD version (CR828-C-2900032), and Trijicon also offers a Coyote Brown MOA Segmented Circle model (CR828-C-2900055) with 1/4 MOA clicks. Because the reticle is in the first focal plane, its mil marks are true at every magnification.
Key features
- MRAD Segmented Circle (FFP): an illuminated circle and center for fast close-range shots, with mil hashes for holdover at higher power.
- Red or green illumination: five red and five green LED settings with an off position between each, powered by one CR2032.
- Exposed locking adjusters: 0.1 MRAD clicks with 29.1 MRAD of total travel, and the turrets lock against accidental moves.
- Wide field at 1x: 105.8 ft at 100 yards on the low end, with 3-4 in of eye relief.
- Repositionable magnification lever: set the throw lever where it suits your rifle and grip.
- Coyote Brown hard anodizing: 6061 aluminum housing, dry-nitrogen filled and waterproof to 10 ft (3 m).
Specifications
| Manufacturer part # | CR828-C-2900056 |
|---|---|
| Trijicon item # | 2900056 |
| UPC | 719307622784 |
| Model | Trijicon Credo 1-8x28 FFP Riflescope - Coyote Brown Anodized (CR828 series) |
| Magnification | 1-8x |
| Objective | 28 mm |
| Tube diameter | 34 mm |
| Reticle | MRAD Segmented Circle |
| Reticle color | Red / Green (dual illuminated, day and night) |
| Focal plane | First (FFP) |
| Illumination | LED, 10 settings (5 red, 5 green) with an off position between each |
| Power source | 1 x CR2032 battery |
| Battery life | Red: 39 hours; green: 94 hours (at a mid-high setting such as 7 of 10) |
| Adjustment | 0.1 MRAD per click |
| Adjustment range | 29.1 MRAD total travel |
| Adjusters | Exposed, locking; 1.012 in from top of tube to top of adjuster |
| Parallax | Fixed (no parallax adjustment) |
| Eye relief | 3 - 4 in (76.2 - 101.6 mm) |
| Exit pupil | 0.46 - 0.14 in (11.68 - 3.56 mm) |
| Field of view | 20° - 2.53°; 105.8 - 13.2 ft @ 100 yd (35.27 - 4.4 m @ 100 m) |
| Length x width x height | 10.8 x 3.2 x 2.6 in (274.32 x 81.28 x 66.04 mm) |
| Weight | 25.6 oz (725.75 g) |
| Housing | 6061 aircraft-grade aluminum, hard anodized, dry-nitrogen filled |
| Finish | Coyote Brown anodized |
| Waterproof | To 10 ft (3 m) |
| Mount | Not included; uses 34 mm rings or mount |
| Warranty | Lifetime of original owner (optics and metal structure); electronics 5 years from manufacture |
In the box
- Scopecoat cover
- 3 mm hex key
- Repositionable magnification knob and replacement screw
- 1 CR2032 battery
- Quick reference guide
- Warranty card
- Vinyl logo sticker
Warranty
Trijicon warrants the optical system and metal structure against defects in material and workmanship for the lifetime of the original owner. The LED illumination electronics carry a 5-year warranty from the date of original manufacture.
