ATN ThOR 5 XD LRF 2-20x Thermal Scope Combo - Rangefinder + BlazeTrek 619 (TIWST51250LRFKBT6)

ATN

MSRP: $5,895.00
$5,295.00
(You save $600.00 )
(No reviews yet) Write a Review
SKU:
U-658175829980
UPC:
658175829980
Weight:
8.80 LBS
Sensor Resolution:
1280 x 1024
Pixel Pitch:
12 micron
Refresh Rate:
60 fps
Magnification:
2-20x
Objective Lens:
50 mm
Field of View:
17.6 x 13.2 deg
Laser Rangefinder:
Yes, up to 1,000 yd
Battery:
Internal Li-ion, 10 hr, USB-C
Weight:
3.05 lb (1.39 kg)
Mount:
30 mm
Bundle Includes:
BlazeTrek 619 thermal monocular (640x512, 1.25-10x)
Warranty:
5 years scope; 3 years BlazeTrek 619
Adding to cart… The item has been added

This ATN combo pairs the ThOR 5 XD LRF 2-20x thermal riflescope, which has a built-in laser rangefinder, with a BlazeTrek 619 thermal monocular for scanning. The scope's 1280 x 1024, 12 micron, 60 fps sensor sits behind a 50 mm objective for a wide 17.6-degree view at 2x. The rangefinder reads out to 1,000 yards and feeds the ballistic calculator automatically. The handheld BlazeTrek covers glassing and tracking.

The scope in this kit is the ThOR 5 XD LRF 2-20x, ATN part TIWST51250LRF: the 1280 x 1024 XD sensor plus the laser rangefinder module. It is not the 640 x 512 ThOR 5 LRF.

Key features

  • Built-in laser rangefinder. Ranges targets out to 1,000 yards and passes the distance straight to the ballistic calculator, so the reticle corrects for drop without manual entry.
  • BlazeTrek 619 thermal monocular included. A 640 x 512, 12 micron handheld viewer with a 19 mm lens, 1.25-10x zoom, OLED display, 6.5-hour battery and IP67 rating for scanning before you shoulder the rifle.
  • 1280 x 1024 Gen 5 sensor. A 12 micron, 60 fps thermal core delivers about four times the pixel count of a 640 x 512 scope for more detail at range.
  • Ballistic calculator. Enter your load and the reticle shifts for drop; profiles store setups for up to six rifles.
  • Smart Mil Dot reticle. Hash-mark spacing adjusts with magnification across the full zoom range, and the Reticle Editor lets you build your own.
  • Recording and streaming. Record to microSD while streaming to the ATN app over Wi-Fi; Recoil Activated Video starts recording when you fire.
  • 10-hour internal battery. Charges over USB-C, and the same port can run an external power bank for long sits.

Specifications

Manufacturer part # (combo)TIWST51250LRFKBT6
Riflescope part #TIWST51250LRF
UPC658175829980
ModelATN ThOR 5 XD LRF 2-20x
Laser rangefinderYes, built in; ranges up to 1,000 yd and feeds the ballistic calculator
Thermal sensor1280 x 1024, 12 micron pixel pitch, 60 fps
CoreATN Gen V (Obsidian V) quad-core
Magnification2-20x (2x base, digital smooth zoom to 20x)
Objective lens50 mm (distributor listing; ATN does not publish focal length)
Field of view17.6 x 13.2 deg
DisplayOLED, 1024 x 768
Eye relief90 mm
Video recording1280 x 960 at 60 fps, dual stream (record + stream), Recoil Activated Video
Ballistic calculatorYes
ReticlesSmart Mil Dot plus multiple patterns and colors; custom reticles via ATN Reticle Editor
ConnectivityWi-Fi (streaming, gallery, controls; iOS & Android), Bluetooth
Sensors3D gyroscope, 3D accelerometer, electronic compass
StoragemicroSD, 4 to 64 GB
BatteryInternal rechargeable Li-ion, USB-C; about 7 hr charge with a 2 A USB charger
Battery life10 hours
Mount30 mm (ATN lists 30 mm HP QDM)
Detection range3,400 yd (ATN product page)
Weather resistanceWeather resistant (no IP rating published)
Operating temperature-20 F to +120 F (-28 C to +48 C)
Dimensions365 x 96 x 73 mm (14.4 in long)
Weight3.05 lb (1.39 kg)
Warranty5 years (registration required)
Country of originUSA
BlazeTrek 619 part #TIMNBLT619
BlazeTrek 619 sensor640 x 512, 12 micron, 50 Hz, <25 mK
BlazeTrek 619 lens / magnification19 mm; 1.25-10x
BlazeTrek 619 field of view22.8 x 18.3 deg
BlazeTrek 619 displayOLED 800 x 600
BlazeTrek 619 batteryInternal rechargeable, about 6.5 hr, USB-C
BlazeTrek 619 storage16 GB internal; video and photo capture
BlazeTrek 619 waterproofIP67
BlazeTrek 619 weight0.7 lb (320 g)
BlazeTrek 619 warranty3 years

In the box

  • Riflescope
  • Scope cover
  • Flip-open lens cap
  • Eyecup
  • USB-C cable
  • Lens tissue
  • BlazeTrek 619 thermal monocular (TIMNBLT619)
  • BlazeTrek cable
  • Case
  • Eyecup
  • Lanyard
  • Wristband
  • Lens tissue

Warranty

ATN covers the ThOR 5 XD against defects in materials and workmanship for 5 years from the date of purchase. Register the product with ATN to validate coverage. ATN lists a 3-year warranty for the BlazeTrek 619 monocular.

Downloads

US sale only. This thermal imaging device is subject to U.S. export controls. We ship it to U.S. addresses only, and it may not be exported or taken outside the United States.
