The AGM FoxBat-8 NL1 is an 8x night vision bi-ocular built for long looks across open ground at night. Behind its 216 mm F/1.8 catadioptric objective, one image intensifier tube and a beam splitter drive two eyepieces, so you observe with both eyes and less fatigue than a monocular over a long session. A tripod and a detachable long-range IR illuminator come in the box, two AA batteries give up to 40 hours of use, and the housing is rated IP65 for wet nights.
The NL1 option fits AGM's Gen 2+ "Level 1" tube with a P43 green phosphor screen, the classic night vision look. Level 1 is the top of AGM's three Gen 2+ grades, with practically no visible spots in the center of the image. If you would rather see in black and white, the NW1 uses the same body with a white phosphor tube; the 3AL1 and 3AW1 step up to Gen 3. Housing, optics and accessories are shared across all four.
Key features
- 8x with a 216 mm lens - 4.5° field of view and focus from 10 m to infinity for detail at distance.
- Two-eye viewing - one tube, two eyepieces; interpupillary distance 57-73 mm, ±5 diopter, 15 mm eye relief.
- IR built in, plus a long-range illuminator - detachable 850 nm, 5 W unit with three power levels and a rechargeable 18650 cell, rated to about 200 m.
- Tube protection - automatic brightness control and a bright-light cut-off.
- Tripod ready - tripod included, 1/4 in socket in the bottom rail and a top Picatinny rail for the illuminator.
- Weather rated - IP65 housing, operating from -40°C to +50°C (-40°F to +122°F).
- 3-year warranty - from AGM Global Vision.
Specifications
| Manufacturer part # | 13F8P822153211 |
|---|---|
| UPC | 850038039813 |
| Tube option | NL1 - Gen 2+ Green Phosphor "Level 1" |
| Image intensifier | Gen 2+ "Level 1" |
| Phosphor | P43 green |
| Cosmetic grade | Level 1: practically no visible spots in Zone 1 (center) |
| Device type | Night vision bi-ocular: one image intensifier tube with beam splitter, two eyepieces |
| Magnification | 8x |
| Field of view | 4.5° |
| Lens system | 216 mm, F/1.8 catadioptric objective |
| Focus range | 10 m to infinity |
| Diopter adjustment | -5 to +5 dpt |
| Exit pupil | 15 mm |
| Eye relief | 15 mm |
| Interpupillary distance | 57-73 mm |
| Built-in IR | Yes, switched with the OFF-ON-IR function knob |
| Detachable IR illuminator | 850 nm LED, 5 W, up to 200 m, High/Mid/Low, one 18650 rechargeable battery, IP65 |
| Bright-light cut-off | Yes |
| Automatic brightness control | Yes |
| Battery | Two 1.5 V AA batteries |
| Battery life | Up to 40 hours |
| Waterproof rating | IP65 |
| Operating temperature | -40°C to +50°C (-40°F to +122°F) |
| Storage temperature | -50°C to +70°C (-58°F to +158°F) |
| Dimensions | 215 × 155 × 146 mm (8.5 × 6.1 × 5.7 in) |
| Weight | 1.76 kg (3.9 lb) without batteries |
| Mounting | Top Picatinny rail for IR illuminator; 1/4 in tripod socket in the bottom Picatinny rail |
| Warranty | 3 years |
In the box
- Night vision bi-ocular
- Lens cap
- Eyecups (2)
- Neck strap
- Lens cloth
- Long-range infrared illuminator
- USB cable for charging the IR illuminator
- Tripod with adapter
- Hard case for storage/transportation
- User manual
Warranty
AGM Global Vision warrants the FoxBat-8 against manufacturing defects in material and workmanship under normal use for three (3) years from the date of purchase. AGM repairs or replaces a covered unit at its discretion, and the warranty is extended to the original purchaser.
Downloads
US sale only. This night vision device is subject to U.S. export controls. We ship it to U.S. addresses only, and it may not be exported or taken outside the United States.
