Trijicon MRO HD 1x25 Red Dot Sight - 68 MOA Circle / 2.0 MOA Dot, Full Co-Witness Mount (MRO-C-2200052)

TRIJICON INC

$868.99
(No reviews yet) Write a Review
SKU:
U-719307616028
UPC:
719307616028
Weight:
1.22 LBS
Magnification:
1x
Objective:
25 mm
Reticle:
68 MOA circle with 2.0 MOA dot (selectable dot only)
Reticle Color:
Red
Brightness Settings:
16 (incl. night vision)
Battery:
CR2032
Click Value:
1/2 MOA
Mount:
Full Co-Witness Mount AC32068 (fixed)
Mount Height:
1.538 in to optical axis
Weight:
6.4 oz with mount
Waterproof:
100 ft (30 m)
Finish:
Matte Black
Adding to cart… The item has been added

The Trijicon MRO HD 1x25 (MRO-C-2200052) is a compact red dot sight with a 2.0 MOA dot inside a 68 MOA segmented circle, supplied on Trijicon's full co-witness mount for AR-pattern rifles with backup iron sights. It is made for rifles, carbines and shotguns, and it is meant to be used with both eyes open so you keep track of what is around the target. One ambidextrous control sets brightness and switches between the full circle-dot reticle and the dot alone, and the large 25 mm objective with a tapered light path keeps the view wide with little tube effect.

This version ships with the MRO Full Co-Witness Mount (AC32068), a fixed mount that installs with a hex key and puts the optical axis 1.538 in. above the rail (Trijicon item 2200052). At that height the dot sits on the same line as standard AR-height iron sights, so folding or fixed irons appear in the middle of the window as a backup. Trijicon also sells this sight with no mount (2200050), on a low mount (2200051) and on a lower 1/3 co-witness mount (2200053). The HD objective lens is reworked to keep the dot sharp behind a magnifier, and Trijicon packages this same mount with its 3x magnifier as the 2200057 kit.

Key features

  • Circle-dot or dot only: a 2.0 MOA dot alone for precise shots, or the dot inside a 68 MOA segmented circle for fast pickup, chosen with the ambidextrous control.
  • Full Co-Witness Mount included: Trijicon AC32068, 1.538 in from rail to optical axis, with screws and hex key.
  • 16 brightness settings: 8 for each reticle mode, including night vision compatible and super-bright settings, from one CR2032 under a tethered cap.
  • Magnifier ready: the re-engineered HD objective keeps the reticle crisp behind a magnifier (not included).
  • Capless adjusters: sub-flush 1/2 MOA windage and elevation adjusters with 70 MOA of travel, built to hold zero under drop and recoil.
  • Sealed 7075-T6 housing: forged, hard anodized and dry-nitrogen filled, rated to 100 ft (30 m) and -60°F to 160°F.

Specifications

Manufacturer part #MRO-C-2200052
Trijicon item #2200052
UPC719307616028
ModelTrijicon MRO HD 1x25 Red Dot Sight
Magnification1x
Objective25 mm
Reticle2.0 MOA dot with 68 MOA segmented circle; selectable dot only or full reticle
Reticle colorRed
IlluminationLED, 16 total settings (8 per reticle mode: 2 night vision, 5 day, 1 super-bright)
BatteryCR2032; tethered battery cap
Battery life2.5 years continuous, dot only at day setting 3 (setting 5 of 8) at 70°F; 75 days continuous with full reticle at the same setting
Adjustment1/2 MOA per click
Adjustment range70 MOA total travel
Eye reliefUnlimited
Sight dimensions (L x W x H, without mount)2.9 x 1.7 x 2.0 in (73 x 43 x 51 mm)
Sight weight (without mount, with battery)4.6 oz (130 g)
Weight with mount6.4 oz (181.44 g)
Mount includedTrijicon MRO Full Co-Witness Mount (AC32068), fixed Picatinny mount; not quick-release
Mount height (rail to optical axis)1.538 in (39.07 mm)
Mount weight1.68 oz (47.63 g)
HousingForged 7075-T6 aluminum, hard anodized, sealed and dry-nitrogen filled
FinishMatte black
Submersion depth100 ft (30 m)
Operating temperature-60°F to 160°F (-51°C to 71°C)

In the box

  • MRO HD 1x25 red dot sight
  • Trijicon MRO Full Co-Witness Mount (AC32068) with 4 screws and hex key
  • Trijicon logo sticker
  • Lens cloth
  • MRO manual
  • Warranty card

Warranty

Trijicon warrants the optical system and metal structure against defects in material and workmanship for the lifetime of the original owner. The illumination system is excluded from that lifetime coverage; MRO electronics are warranted for five years from the date of original manufacture.
