The Trijicon ACOG 5.5x50 BAC (TA55A) is a fixed 5.5x riflescope with a red chevron reticle calibrated for .308 / 7.62, made for AR-10 pattern and other .308-class rifles that need more reach than a 4x sight gives. Fiber optics light the chevron in daylight and a tritium lamp lights it after dark, so there is no battery to fail and no switch to remember. The 50 mm objective and 5.5x power make this the longest-reaching chevron ACOG in Trijicon's standard line, and the TA51 thumbscrew mount clamps straight onto a Picatinny rail.
This is the .308 / 7.62 version. Trijicon's TA55 uses the same 5.5x50 housing and red chevron, but its bullet drop marks are set for .223 / 5.56, so match the model to your caliber. You zero with the tip of the chevron at 100 meters, and the base of the chevron is 5.53 MOA wide, which covers 19 in. at 300 meters for quick range estimates on a man-size target. Eye relief is 2.2 in., longer than the 4x32 models.
Key features
- Red chevron BDC reticle: drop marks calibrated for .308 / 7.62, with the chevron tip as the 100 m aiming point.
- Battery-free illumination: fiber optics adjust reticle brightness to the light in daytime, and tritium lights it in low light and darkness.
- Both eyes open: Trijicon lists the Bindon Aiming Concept for this model for faster target pickup with both eyes open.
- 5.5x50 optics: 18.4 ft field of view at 100 yards and 5 clicks per inch at 100 yards for fine zero adjustments.
- Ready to mount: ships with the TA51 thumbscrew flattop adapter and a 5.5x50 Scopecoat cover.
- Fixed-power forged housing: matte black aluminum with few moving parts; Trijicon tests ACOGs against recoil from .22 LR up to .50 BMG.
Specifications
| Manufacturer part # | TA55A |
|---|---|
| Trijicon item # | 100175 |
| UPC | 719307302037 |
| Model | Trijicon ACOG 5.5x50 BAC Riflescope, .308 / 7.62 BDC |
| Magnification | 5.5x |
| Objective | 50 mm |
| Reticle | Chevron, bullet drop compensating; zero with the chevron tip at 100 m; chevron base 5.53 MOA wide (19 in. at 300 m) for range estimation |
| Reticle color (day / night) | Red / Red |
| Caliber calibration | .308 / 7.62 |
| Illumination | Fiber optics and tritium; no battery |
| Bindon Aiming Concept (BAC) | Yes |
| Adjustment | 5 clicks per in. @ 100 yd |
| Eye relief | 2.2 in (55.88 mm) |
| Exit pupil | 0.35 in (8.89 mm) |
| Field of view | 3.5°; 18.4 ft @ 100 yd (6.13 m @ 100 m) |
| Length x width x height | 12 x 2.5 x 2.7 in (304.8 x 63.5 x 68.58 mm) |
| Weight | 25.6 oz (725.75 g) |
| Mount | TA51 Flattop Thumbscrew Mount |
| Housing | Forged aluminum |
| Finish | Matte black |
In the box
- Thumbscrew flattop adapter (TA51)
- 5.5x50 Scopecoat (TA65)
- LensPen (TA56)
- Lanyard assembly for adjuster caps (TA71E)
- Trijicon logo sticker (PR15)
- ACOG manual
- Warranty card
Warranty
Trijicon warrants its products against defects in material and workmanship for the lifetime of the original owner; that coverage applies to the optical system and metal structure. The illumination system is excluded from the general warranty, but the tritium lamp in fiber-optic ACOG models is warranted to glow for 15 years from the date of manufacture. Normal tritium decay is not a defect.
