The Steiner T6Xi 5-30x56 is the highest-magnification T6Xi, a first focal plane scope for precision rifle competitors, long-range shooters and duty marksmen who need to see small targets far away. It reaches 30x on top, and the 56 mm objective keeps the picture bright at high power. It is made in the U.S.A. on a one-piece 34 mm tube, 15.75 in long and 34.5 oz. This listing is Steiner item 5125.
This is the SCR2 MIL version, the current reticle for this size. Next to the T6Xi 3-18x56 (item 5119), it trades some low-end field of view and elevation travel (26 MIL versus 35 MIL) for 30x top-end magnification, which helps with spotting your own impacts and small steel at distance. Steiner recommends a 25 MOA canted base to make full use of the elevation travel.
Key features
- 6x zoom, 5-30x56. A 22-4 ft field of view at 100 yd and 30x for small or distant targets.
- SCR2 MIL reticle, first focal plane. A precise center and a structured lower hold grid for elevation and wind holds, with a clean upper field for spotting impacts.
- 0.1 mrad locking turrets. 26 MIL of elevation and 25 MIL of windage per Steiner's product page, with a resettable zero and zero click stop.
- Never-Lost elevation. The scale changes after the first 120-click turn, so you always know which rotation you are on.
- Illuminated. 11 brightness levels with battery-saver off positions between them and low settings for night vision; CR2450 battery.
- Side focus from 25 yd. Parallax adjusts from 25 yd to infinity; the eyepiece diopter locks once set.
- Submersible to 33 ft. Nitrogen filled, fogproof and shockproof, with a sunshade included.
Specifications
| Manufacturer part # | 5125 |
|---|---|
| UPC | 000381851253 |
| Magnification | 5-30x |
| Objective lens | 56 mm |
| Tube diameter | 34 mm |
| Focal plane | First (FFP) |
| Reticle | SCR2 MIL, illuminated |
| Field of view | 22-4 ft at 100 yd |
| Eye relief | 3.5-3.3 in |
| Exit pupil | 9.7-1.8 mm |
| Click value | 0.1 mrad |
| Elevation travel | 26 MIL |
| Windage travel | 25 MIL |
| Elevation turret | Never-Lost, locking, resettable zero with zero click stop, second-rotation indicator |
| Windage turret | Locking |
| Parallax / focus | Side focus, 25 yd to infinity |
| Length | 15.75 in |
| Weight | 34.5 oz |
| Illumination | 11 levels with a battery-saver off position between each; low settings for use with night vision |
| Diopter | +2 to -3, locking ring |
| Battery | CR2450 |
| Waterproof | Submersible to 33 ft, nitrogen filled, fogproof |
| Operating temperature | -15 F to +160 F |
| Finish | Matte black |
| Mounting | 34 mm rings; Steiner recommends a 25 MOA canted base |
| Made in | USA (designed, machined and assembled) |
| Warranty | Steiner Heritage Warranty |
In the box
- Riflescope
- Flip-up lens caps
- Sunshade
- 2 mm hex wrench for resetting turret zero
Warranty
Covered by the Steiner Heritage Warranty. Steiner will repair or replace the scope at no charge for the life of the product when sold in the U.S. and Canada; electronic components such as the illumination module carry a 3-year warranty. No warranty card or receipt is needed, and coverage transfers to later owners. It does not cover loss, theft or deliberate damage.
