The Nocpix RICO 2 H75R is a 640×512 thermal riflescope with a 75 mm f/1.0 lens and a built-in 1,200-yard laser rangefinder, for hunters who want long reach without paying for a 1280 sensor. Its 4× base magnification and narrow 5.9° field put plenty of pixels on a distant animal, and Nocpix rates its detection range at 4,250 yards. The rangefinder reads to ±1 yard and feeds the onboard ballistic calculator, which moves the aim point for the measured range.
RICO 2 comes in three sensor tiers, named by the first letter of the model: S uses the 1280×1024 Nocpix 1280 core, H the 640×512 Nocpix 640, and L the 384×288 Nocpix 384. All three use 12 µm pixels and refresh at 60 Hz, and the number in the model name is the objective lens size in millimeters. The H75R uses the same 640 sensor as the H50R, but its larger 75 mm lens gives a higher 4× base magnification and longer detection range. It shares its housing and recoil-reducing mount with the 1280-resolution S75R.
Key features
- 640×512 Nocpix sensor. 12 µm pixels, <15 mK NETD, 60 Hz refresh.
- 75 mm f/1.0 germanium lens. 4× base with 8× stepped digital zoom on a zoom lever.
- 1,200-yard laser rangefinder. ±1 yd accuracy, with a built-in ballistic calculator and six zero profiles.
- Round 2560×2560 AMOLED display. Eight reticles, seven color palettes and picture-in-picture.
- Record what you shoot. 32 GB storage for photo, video and recoil-activated video; Wi-Fi to the Nocpix app.
- Two swappable IBP-5 batteries. 4,400 mAh packs rated 5.5+ hours each, plus USB-C power and a magnetic charging port.
- Recoil-reducing QD mount. Spring-damped quick-detach Picatinny mount. IP67, rated for .300 Win. Mag / 7mm Mag recoil.
Specifications
| Manufacturer part # | RICO2-H75R |
|---|---|
| UPC | 850048751576 |
| Sensor | Nocpix 640, 640×512 uncooled thermal |
| Pixel pitch | 12 µm |
| Thermal sensitivity (NETD) | <15 mK (≤15 mK) |
| Refresh rate | 60 Hz |
| Objective lens | 75 mm f/1.0, germanium, manual focus |
| Base (optical) magnification | 4× |
| Digital zoom | 8× (stepped) |
| Field of view | 5.9° × 4.7° (H × V) |
| Detection range | 4,250 yd |
| Display | Round AMOLED, 2560×2560 (1.03 in, per Nocpix datasheet) |
| Eye relief | 60 mm |
| Diopter | −5 to +5 |
| Laser rangefinder | Integrated, 1,200 yd, ±1 yd accuracy; Class 3R, 900 nm |
| Ballistics | Built-in calculator, 5 ballistic profiles, 6 zero profiles (A–F) |
| Reticles | 8 (7 static, 1 DIY), 8 reticle colors |
| Color palettes | White Hot, Black Hot, Red Hot, Color, Violet, Crimson, Viridian |
| Recording | Photo, video and recoil-activated video; 32 GB onboard storage |
| Connectivity | Wi-Fi (Nocpix app), USB-C power/data |
| Battery | 2 × IBP-5 rechargeable Li-ion, 4,400 mAh each; USB-C external power |
| Runtime | 5.5+ hours per IBP-5 pack |
| Start-up | Under 10 seconds; instant from standby |
| Mount | QD Picatinny with included recoil-reducing (spring-damped) mount |
| Housing | Magnesium alloy |
| Waterproof rating | IP67 |
| Recoil rating | 1,000 g/s² (.300 Win. Mag / 7mm Mag) |
| Operating temperature | −4°F to 122°F |
| Storage temperature | −12°F to 167°F |
| Dimensions (L × W × H) | 13.23 × 4.57 × 3.54 in |
| Weight | 44.09 oz |
| Warranty | 5 years |
In the box
- RICO 2 H75R thermal riflescope
- 75 mm objective lens cap
- Recoil-reducing QD Picatinny mount
- M5 screws and 3 mm hex key
- 2 × IBP-5 battery packs
- IBP-5 battery charger
Warranty
Nocpix covers the RICO 2 with a 5-year warranty through iRay USA.
Downloads
US sale only. This thermal imaging device is subject to U.S. export controls. We ship it to U.S. addresses only, and it may not be exported or taken outside the United States.
