The Garmin Xero L60i is a 7x32 laser rangefinder with a full-color graphic overlay, built for hunters and long-range shooters who want ranging, mapping and ballistics in one handheld unit. Instead of a plain distance readout, a 960 x 540 augmented-reality display places range, maps, waypoints and firing solutions over the view through the glass. Garmin rates it to range animals to 1,500 yards and trees to 2,000 yards in full sun, and it pairs over Bluetooth with the Garmin Explore app and the AB Quantum app.
Ranging is only part of the job here. Laser Locate drops a GPS waypoint on whatever you range, sensor locate projects a waypoint past rangeable distance, and visual recall uses the overlay to guide you back to a spot after you lose sight of it. Onboard TopoActive mapping, a compass and elevation profiles let you navigate to a downed animal while looking through the unit.
Key features
- Augmented-reality display: a full-color overlay shows distance, location, maps, ballistics and navigation over the scene, and dims automatically in low light.
- Long-reach ranging: 1,500 yd on animals, 2,000 yd on trees and 5,500 yd on retro-reflective targets in full sun, with +/- 0.25 m accuracy out to 1,000 m.
- Applied Ballistics Elite: the onboard solver runs through the AB Quantum Garmin app; archers get arrow data such as maximum arrow height and angle-compensated range.
- Laser Locate and sensor locate: mark ranged objects as GPS waypoints, or project a waypoint beyond the laser's reach.
- 7x32 optics: 7-degree field of view (365 ft at 1,000 yd), 18 mm eye relief, 4.6 mm exit pupil and +/- 4 diopter focus.
- Weather-ready: IPX7 water rating, -4 to 140 F operating range, USB-C interface and 2 AAA lithium batteries included.
Specifications
| Manufacturer part # | 010-02691-00 |
|---|---|
| UPC | 753759332471 |
| Magnification | 7x |
| Objective lens | 32 mm |
| Field of view | 7 degrees (365 ft at 1,000 yd) |
| Eye relief | 0.71 in (18 mm) |
| Exit pupil | 4.6 mm |
| Diopter adjustment | +/- 4 diopters |
| Display | Full-color DLP augmented-reality overlay, 960 x 540 pixels, automatic brightness |
| Range, full sun | Animals 1,500 yd (1,375 m); trees 2,000 yd (1,800 m); retro-reflective 5,500 yd (5,000 m) |
| Range, optimal conditions | Animals 3,000 yd (2,775 m); trees 4,000 yd (3,600 m); retro-reflective 7,500 yd (7,000 m) |
| Accuracy | +/- 0.25 m to 1,000 m; +/- 1.0 m beyond 1,000 m |
| Precision | +/- 0.1 m |
| Laser beam divergence | 0.5 x 0.5 mrad |
| Laser classification | Class 1 |
| Ballistics | Applied Ballistics Elite solver (via AB Quantum Garmin app); archery ballistics; angle-compensated distance |
| Navigation | Onboard TopoActive mapping, Laser Locate, sensor locate, visual recall, compass, barometer |
| Connectivity | Bluetooth; Garmin Explore app |
| Memory | 32 GB internal |
| Interface | USB-C |
| Battery | 2 AAA lithium batteries (included) |
| Battery life | 1,400 ranges (1 sec range, 10 sec display) |
| Water rating | IPX7 |
| Operating temperature | -4 to 140 F (-20 to 60 C) |
| Dimensions | 4.94 x 3.53 x 1.99 in (125.41 x 89.66 x 50.59 mm) |
| Weight | 0.80 lb (362.88 g) without battery; 0.849 lb (385.1 g) with battery |
In the box
- Xero L60i laser rangefinder
- Carrying case
- 2 AAA lithium batteries
- Power/data cable
- Documentation
Warranty
Garmin's consumer limited warranty covers non-aviation products against defects in materials or workmanship for one year from the date of purchase.
