The VDU5-25TR5TAN is EOTECH's Vudu 5-25x50 first focal plane riflescope in tan, fitted with the illuminated Horus TREMOR5 grid reticle for shooters who prefer to hold corrections instead of dialing every shot. It measures just 11.2 inches overall, which keeps a short-barreled precision rifle balanced and leaves rail space for a clip-on thermal or night vision unit in front of the scope. The tan finish matches earth-tone chassis and Cerakote builds where a black tube would stand out.
This is the tan Horus TREMOR5 version with MRAD turrets. The TREMOR5 lays a 0.2-mil Horus grid below the crosshair, with Time-of-Flight wind dots you calibrate to your load and density altitude, so elevation holds, wind holds and second-shot corrections come straight off the reticle. The black version is VDU5-25FFTR5. The tan MD4 model (VDU5-25MD4TAN) uses a simpler MOA mil-dot style reticle with 0.25 MOA clicks instead.
Key features
- Horus TREMOR5 in the first focal plane: grid and holdover values stay accurate at any magnification from 5x to 25x.
- Matched MRAD turrets: 0.1 MRAD clicks, 10 MRAD per revolution, 29 MRAD of elevation and 23 MRAD of windage travel.
- Locking elevation with EZ Chek zero stop: pull the turret up to dial and push it down to lock, then return to zero by feel.
- Ten-level illumination: push buttons on the left side bring the reticle back at your last setting. It turns off on its own after about two hours idle.
- Compact 34 mm one-piece tube: aircraft-grade aluminum, nitrogen purged and O-ring sealed against fog, water and dust.
- XC High-Density glass: low-dispersion, multi-coated lenses with a side focus dial for parallax.
- Ready to mount: ships with a removable throw lever and a sunshade.
Specifications
| Manufacturer part # | VDU5-25TR5TAN |
|---|---|
| UPC | 672294110347 |
| Color | Tan |
| Reticle | Horus TREMOR5, illuminated (MRAD) |
| Focal plane | First (FFP) |
| Magnification | 5-25x |
| Objective | 50 mm |
| Tube | 34 mm one-piece aluminum |
| Click value | 0.1 MRAD |
| Per revolution | 10 MRAD |
| Elevation travel | 29 MRAD |
| Windage travel | 23 MRAD |
| Zero stop | EZ Chek |
| Parallax | Side focus dial |
| Illumination | 10 levels, 2-hr auto shut-off |
| Battery | CR2032 (about 500 hr at setting 5) |
| Eye relief | 5x: 2.96-3.71 in; 25x: 3.27-3.63 in |
| Field of view @ 100 yd | 23.3 ft (5x) to 4.7 ft (25x) |
| Exit pupil | 5.5 mm (5x) to 2.1 mm (25x) |
| Length | 11.2 in (285 mm) |
| Weight | 29.5 oz (835 g) with battery |
| Rings | 34 mm |
| Made in | Japan |
In the box
- Vudu 5-25x50 FFP riflescope
- Throw lever
- Sunshade
- CR2032 battery
- Operator manual
- Reticle manual
Warranty
Covered by EOTECH's NoBS Limited Lifetime Warranty for Vudu riflescopes. EOTECH will repair or replace the scope for defects in materials and workmanship; you don't need to be the original owner or show proof of purchase. Theft, loss, abuse, cosmetic wear and non-EOTECH repairs are excluded.
