EOTECH OGL C On-Gun Laser - Black, Green Visible and IR Aiming Lasers with IR Illuminator (EOT-OGL-C-B)

EO Tech

MSRP: $2,199.00
$1,999.00
(You save $200.00 )
(No reviews yet) Write a Review
SKU:
U-672294470533
UPC:
672294470533
Weight:
1.40 LBS
Lasers:
Green visible aim, IR aim, IR illuminator
Laser Class:
Class 3R (commercial, eye-safe)
Visible Laser:
Green 515 nm, 0.5 mW
IR Aim Laser:
830 nm, 0.67 mW
IR Illuminator:
850 nm VCSEL, 30 mW, spot to flood
Battery:
CR123
Run Time:
Up to 9 hours
Waterproof:
16 ft (5 m)
Mount:
Picatinny (top or side)
Color:
Black
Night Vision Use:
IR aim laser and illuminator require night vision
Warranty:
3-year limited
Adding to cart… The item has been added

The EOTECH OGL C is a rail-mounted aiming laser that combines a green visible laser, an infrared aiming laser and an infrared illuminator in one black aluminum housing, for night vision users and shooters who want a visible laser for low light. It is the commercial, eye-safe version of EOTECH's On-Gun Laser, rated Class 3R and sold to the general public. The housing is about the size of a deck of cards and mounts on the top rail or either side of a handguard. A large fire button handles momentary or constant-on use, and a remote switch is included for the rear jack.

This is the black version (EOT-OGL-C-B); the tan model, EOT-OGL-C-T, is otherwise identical. Do not confuse it with the higher-powered OGL Standard (Class 3B), which EOTECH restricts to military and law enforcement and does not sell online. The infrared beams are visible only through night vision devices.

Key features

  • Co-aligned aim lasers: 515 nm green visible and 830 nm IR aiming lasers share one windage and elevation adjustment, so one zero covers both.
  • Adjustable IR illuminator: 850 nm VCSEL illuminator on its own adjustment, with a sliding lever that moves the beam from a wide flood to a tight spot.
  • Eight-position mode switch: off, visible high and low, and IR aim, illuminator and combined modes, with blue safety screws to lock out high power.
  • Flexible activation: momentary press, double-tap for constant on with a 5-minute shut-off, and a visible-laser override; the IR aim laser can pulse at 2, 4 or 8 per second.
  • Remote switch ready: Crane-type jack at the rear, with the included remote cable switch.
  • Field adjustments: about 0.2 MRAD clicks with 50 MRAD of total travel on the aim lasers.
  • Rugged build: aluminum housing, tethered battery cap and protective covers, water resistant to 16 ft (5 m).

Specifications

Manufacturer part #EOT-OGL-C-B
UPC672294470533
ColorBlack
Laser classClass 3R (eye-safe commercial power)
Visible aim laserGreen, 515 nm, up to 0.5 mW, under 0.5 MRAD divergence
IR aim laser830 nm, up to 0.67 mW, under 0.5 MRAD divergence
IR illuminator850 nm VCSEL, up to 30 mW; spot 30 MRAD or more, flood 105 MRAD or more
Modes8-position selector (off, 2 visible, 5 IR)
IR aim pulseContinuous, 2, 4 or 8 pulses per second
AdjustmentAbout 0.2 MRAD per click, 50 MRAD total
Battery(1) CR123 lithium
Run timeUp to 9 hours
Water resistance16 ft (5 m)
MountMIL-STD-1913 Picatinny, top or side
RemoteCrane-type jack; remote cable switch included

In the box

  • OGL C laser
  • Zippered soft carrying case
  • Multi-tool
  • Remote cable switch
  • CR123 battery
  • Operator's manual and registration/warranty card

Warranty

EOTECH covers OGL laser aiming products with a 3-year limited warranty against manufacturing defects in material and workmanship under normal use, from proof of first purchase. EOTECH will repair or replace the product at its discretion.

Downloads

US sale only. This infrared laser device is subject to U.S. export controls. We ship it to U.S. addresses only, and it may not be exported or taken outside the United States.


State & Local Restrictions — Order Reviewed Before It Ships
Some firearms, magazines, and accessories are restricted or prohibited in certain states, cities, and counties, and these laws change often. Each order is manually reviewed against the current laws for your shipping address before it ships. If we can't lawfully ship this item to your location, we'll contact you to cancel or adjust your order and issue a refund. You're responsible for knowing and following the laws where you live — if you're unsure, please check or ask us before ordering.
