ATN ThOR 5 LRF 640 5-40x Thermal Rifle Scope - 640x480 12 Micron, Laser Rangefinder (TIWST5675LRF)

AMERICAN TECH NETWORK COR

$3,995.00
(No reviews yet) Write a Review
SKU:
U-658175123583
UPC:
658175123583
Weight:
6.96 LBS
Sensor Resolution:
640 x 480
Pixel Pitch:
12 micron
Refresh Rate:
60 fps
Magnification:
5-40x
Objective Lens:
75 mm
Field of View:
5.9 x 4.4 deg
Laser Rangefinder:
Yes, 1,000 yd
Detection Range:
3,500 yd
Battery:
Internal Li-ion, 10 hr, USB-C
Weight:
2.91 lb (1.32 kg)
Mount:
30 mm
Warranty:
5 years
Adding to cart… The item has been added

The ATN ThOR 5 LRF 640 5-40x is the longest-reach scope in the ThOR 5 LRF 640 line, built for shooters who glass open country and take long shots on coyotes and hogs after dark. A 75 mm lens in front of a 640 x 480, 12 micron, 60 fps sensor gives a 5.9 x 4.4 degree view at 5x, and ATN rates detection at 3,500 yards. The built-in laser rangefinder reads to 1,000 yards and hands that distance to the ballistic calculator, which shifts the aim point for drop. Video recording, Wi-Fi streaming and a 10-hour battery round out the package.

This is the 5-40x LRF model. It has the most magnification and the narrowest field of view of the ThOR 5 640 lenses, and at 2.91 lb and about 14 inches it is the heaviest. The 2-16x, 3-24x and 4-32x LRF versions are wider and lighter, and the non-LRF 5-40x keeps the same lens without the rangefinder.

Key features

  • Longest reach in the series. A 75 mm lens and 5x base power give ATN's highest ThOR 5 640 detection rating, 3,500 yards.
  • Built-in laser rangefinder. Ranges to 1,000 yards and sends the distance to the ballistic calculator automatically.
  • 640 x 480 Gen 5 sensor. 12 micron pixels at 60 fps, processed by ATN's quad-core engine and shown on a 1024 x 768 OLED.
  • Smart Mil Dot reticle. Holdover marks scale with zoom from 5x to 40x; load your own designs through the Reticle Editor.
  • Record what you shoot. Dual stream video to microSD and the ATN app, with Recoil Activated Video.
  • 10-hour runtime. Internal Li-ion battery with USB-C charging and external power-bank support.
  • Familiar scope layout. 30 mm tube format with 90 mm of eye relief and a weather-resistant housing.

Specifications

Manufacturer part #TIWST5675LRF
UPC658175123583
ModelThOR 5 LRF 640 5-40x
Laser rangefinderYes, built in; ranges to 1,000 yd and feeds the ballistic calculator
Thermal sensor640 x 480, 12 micron pixel pitch, 60 fps
CoreATN Gen V (Obsidian V) quad-core
Magnification5-40x (5x base, digital smooth zoom to 40x)
Objective lens75 mm (distributor listings; ATN does not publish focal length)
Field of view5.9 x 4.4 deg
DisplayOLED, 1024 x 768
Eye relief90 mm
Video recording1280 at 60 fps; dual stream (record + stream); Recoil Activated Video
Ballistic calculatorYes
ReticlesSmart Mil Dot plus multiple patterns and colors; custom reticles via ATN Reticle Editor
ConnectivityWi-Fi (streaming, gallery, controls; iOS & Android), Bluetooth
Sensors3D gyroscope, 3D accelerometer, electronic compass
Other featuresSmooth zoom, ATN Radar, built-in microphone
StoragemicroSD, 4 to 64 GB
BatteryInternal rechargeable Li-ion, USB-C; about 7 hr charge with a 2 A USB charger
Battery life10 hours
Mount30 mm tube; ATN lists a 30 mm HP QDM mount (rings not shown in this model's included accessories)
Detection range3,500 yd (ATN product page)
Weather resistanceWeather resistant (no IP rating published)
Operating temperature-20 F to +120 F (-28 C to +48 C)
Dimensions355 x 76 x 56 mm (14.0 x 3.0 x 2.2 in)
Weight2.91 lb (1.32 kg)
Warranty5 years (registration required)
Country of originUSA

In the box

  • Riflescope
  • Scope cover
  • Flip-open lens cap
  • Eyecup
  • USB-C cable
  • Lens tissue

Warranty

ATN covers the ThOR 5 against defects in materials and workmanship for 5 years from the date of purchase. Register the scope with ATN to validate coverage.

Downloads

US sale only. This thermal imaging device is subject to U.S. export controls. We ship it to U.S. addresses only, and it may not be exported or taken outside the United States.
