The AGM Rattler-C V2 19-256 is the entry-level thermal clip-on in AGM's Rattler-C V2 line, made for hunters who want to add thermal to the day scope they already shoot without buying a dedicated thermal riflescope. It sits in front of your scope at 1x, so your existing reticle and zero stay in use. The 12-micron VOx sensor has 256x192 resolution, refreshes at 50 Hz and is rated below 35 mK.
This is the smallest-sensor, shortest-lens version of the Rattler-C V2. The 19 mm F/1.0 lens gives the widest view in the family, 9.3° x 6.9° (about 49 x 36 ft at 100 yd), and it focuses as close as 0.5 m. AGM rates detection at 1,000 m on a 6 ft target, so it is aimed at close and mid-range work such as hogs in fields and coyotes coming to a call. The 35-384 and 50-640 versions add more resolution and reach. AGM suggests pairing it with an LPVO or a magnified scope set at about 1x to 6x. An ADM Picatinny mount with a 1.5 in centerline is included; to attach it directly to a scope's objective bell you need a Front Q-R adapter, sold separately. Battery life is the best in the line at 11.5 hours per NE-4400 cell, two are included, and a USB-C power bank can extend it. The unit weighs 1.10 lb without mount or battery.
Key features
- Keeps your day scope and zero - 1x clip-on that mounts ahead of an LPVO or magnified scope, ideally 1x to 6x.
- Widest Rattler-C V2 view - 9.3° x 6.9° (about 49 x 36 ft at 100 yd) from a 19 mm F/1.0 lens.
- 256x192 sensor at 50 Hz - 12-micron VOx detector under 35 mK, four palettes and 1x to 8x digital zoom.
- 11.5 hours per battery - two removable NE-4400 cells included, plus 5 V USB-C external power.
- Record and stream - video with audio, stills and shot-activated recording to 16 GB, plus a Wi-Fi hotspot.
- Field-ready - IP67, rated for 1,000 g recoil and -22°F to 131°F.
Specifications
| Manufacturer part # | 314208560103R921 |
|---|---|
| UPC | 810027771841 |
| Device type | Thermal imaging clip-on (mounts in front of a day scope) |
| Image sensor | 12 µm VOx uncooled focal plane array |
| Sensor resolution | 256 × 192 |
| NETD | Less than 35 mK (25°C, F# = 1.0) |
| Refresh rate | 50 Hz |
| Lens system | 19 mm, F/1.0 |
| Optical magnification | 1× |
| Digital magnification range | 1× - 8× |
| Recommended day optics | LPVO and magnified scopes, ideally 1× to 6× |
| Field of view | 9.3° × 6.9° (49 × 36 ft at 100 yd) |
| Detection range (6 ft object) | 1,000 m/yd |
| Minimum focusing distance | 0.5 m to infinity |
| Exit pupil | 22 mm |
| Eye relief | 10 mm |
| Display | 0.39 in OLED, 1024 × 768 |
| Palettes | Black Hot, White Hot, Red Hot, Fusion |
| Scene modes | Cold, Warm |
| Image processing | PIP, hot tracking, defective pixel correction, burn prevention; FFC auto/manual/external |
| Distance measurement | Stadiametric rangefinder (no laser) |
| Recording | Video and audio recording, image capture, shot-activated recording (SAR) |
| Storage | Built-in EMMC, 16 GB |
| Wi-Fi | Wi-Fi hotspot for live streaming and recording via mobile app |
| Battery | One replaceable rechargeable NE-4400 Li-ion (two included) |
| Battery life | 11.5 hours (25°C, hotspot off) |
| External power | 5 VDC / 2 A via USB Type-C |
| Recoil rating | 1,000 g / 0.4 ms |
| Protection rating | IP67 |
| Operating temperature | -30°C to 55°C (-22°F to 131°F) |
| Dimensions (without mount) | 184 × 68 × 67 mm (7.2 × 2.7 × 2.6 in) |
| Weight (without mount and battery) | 0.5 kg (1.10 lb) |
| Mount | ADM Picatinny mount included (1.5 in centerline height); Front Q-R adapter for mounting to a day scope sold separately |
| Warranty | 5 years |
In the box
- Rattler-C V2 thermal imaging clip-on
- Mount
- Two NE-4400 batteries
- NE-4400 charger
- USB cable
- Lens cloth
- Manual
- Carrying case
Warranty
AGM Global Vision covers the Rattler-C V2 19-256 with a 5-year warranty against defects in materials and workmanship for products bought in the United States.
Downloads
US sale only. This thermal imaging device is subject to U.S. export controls. We ship it to U.S. addresses only, and it may not be exported or taken outside the United States.
